EP/NN/CC Fabric Conveyor Belt
Belt Structure
EP Fabric Conveyor Belt:This kind of belt has good elasticity,low elongation in use,heat resistant and anti-shock,suitable for middle/long distance and high speed conveying with heavy load capacity.
NN Fabric Conveyor Belt:This kind of belt has good elasticity and high tensile strength,anti-shock,warp resistant,easy to trough and low elongation,suitable for for middle/long distance and high speed conveying with heavy load capacity.
Cotton Fabric Conveyor Belt(CC56):A kind of traditional conveyor belt,suitable for short/middle distance conveying.
Specification Details
| Belt Type | Fabric Type | Fabric Thickness (mm) | Ply | Width (mm) | Top Cover Thickness (mm) | Total Thickness (mm) | Tensile Strength (Mpa) |
| EP Conveyor Belt | EP100 | 1 | 1-10 | 300-6000 | 1-20 | 5-40 | 8-25 |
| EP125 | 1 | ||||||
| EP150 | 1.1 | ||||||
| EP200 | 1.2 | ||||||
| EP250 | 1.4 | ||||||
| EP300 | 1.6 | ||||||
| EP350 | 1.8 | ||||||
| EP400 | 2 | ||||||
| EP500 | 2.2 | ||||||
| NN Conveyor Belt | NN100 | 1 | 1-10 | 300-6000 | 1-20 | 5-40 | 8-25 |
| NN125 | 1 | ||||||
| NN150 | 1.1 | ||||||
| NN200 | 1.2 | ||||||
| NN250 | 1.4 | ||||||
| NN300 | 1.6 | ||||||
| NN350 | 1.8 | ||||||
| NN400 | 2 | ||||||
| NN500 | 2.2 | ||||||
| Cotton Conveyor Belt | CC56 | 1 | 1-10 | 300-6000 | 1-20 | 5-40 | 8-25 |
